Item |
Characteristics |
|
Size and its tolerance |
ΦD |
5 |
6 |
8 |
10 |
12 |
13 |
16 |
18 |
22 |
25 |
26 |
|
|
F±0.5 |
2.0 |
2.5 |
3.5 |
5.0 |
7.5 |
10 |
12.5 |
|
|
d±0.1 |
0.5 |
0.6 |
0.8 |
|
|
Rated working voltage |
6.3~450VDC |
|
Capacitance range |
0.1~10000μF(+20℃, 100 or 120Hz) |
|
Capacitance Tol. |
±20% |
|
Dissipation factor tg |
At +20℃ and 100 or 120Hz, for CR>1000μF, tg add 0.02 per another 1000μF
 |
|
Leadage current IL |
A grade ≤0.03.CR.UR or 5μA(≤100VDC) whichever is greater
≤0.03.CR.UR + 10μA(≤160VDC)
B grade GB5995-86
At +20℃, after 2 minutes application of UR |
|
Load life |
At +85℃ after UR applied for 1000 hours.
 |
|
Shelf life |
After shelf for 500 hours(without voltage applied) at +85℃, then restored for 16 hours at room temp.
 |
|
|
