Electrical life: 2000 operations per switch 24VDC 25mA

Non-switching rating: 100mA 50VDC

Switching rating: 25mA 24VDC

Insulation resistance: 100MΩ/min. (at 500VDC)

Dielectric strength: 500VAC, 1min.

Capacitance: Max.5pF

The loop: Single contact single selection

Operating force: 8N(max.)

Stroke: 2.00mm

Operation temp.: 20℃~70℃

Storage temp.: -40℃~85℃
