Actuating force: 2.5±0.5N

Actuating travel: 0.25+0.1 / -0.1mm

End stop strength: 50N / 3S

Life time: >100000 actuations

Soldering methods: Reflow

Solderability: 245℃ / 5 sec (IEC 60068-2-58 test td)

Resistance to soldering heat: 260℃ / 10 sec (IEC 60068-2-58 test td)

Switch rating: DC 12V, 50mA

Withstanding voltage: AC 500V

Contact resistance: Max.100mΩ

IP-protection: IP 40
